The ESP-ME3 offers 4 to 22 station options, perfect for residential or light commercial use. Easily expand irrigation by adding station modules without disrupting the controller. Enhance it to a SMART controller with EPA WaterSense certification by integrating the LNK2 WiFi module and a WR2 rain sensor. Access programming and monitoring via app. For additional water oversight and safeguarding against system malfunctions, consider installing a flow sensor.
Features
- Built-in flow-sensing capabilities
- Easy to install indoors or outdoors with pre-installed power cord
- Back-lit LCD display for improved visibility in low-light and direct sun conditions
Operating Specifications
- Station timing: 1 minute to 6 hours
- Seasonal Adjust: 5% to 200%
- Max operating temperature: 149°F (65°C)
Electrical Specifications
- Input required: 120V∿, 60Hz, 0.3A (International models: 230V∿, 50-60Hz, 0.136A)
- Output: 25.5V∿, 60Hz, 1A (International models: 24V∿, 50-60Hz, 1.0A)
- Master Valve/Pump Start Relay
- Operating Voltage: 24VAC 50/60Hz
- Max Coil Inrush: 11VA
- Max Coil Holding: 5VA
- Idle/Off power draw 0.06 amps at 120VAC
- Power back-up not required. Nonvolatile memory permanently saves the current programming and a 10-year life lithium battery maintains the controllers time and date during power outages.
Certifications
- z120V Models: cULus [US and Canada], FCC Part 15b [US], CAN ICES-3(B)/NMB-3(B) [Canada], NOM-001-SCFI-2018 [Mexico]
- 230V Models: CE [European Union], IP24, RCM [Australia and New Zealand], IRAM [Argentina], INMETRO [Brazil], C [Morocco], SABS [South Africa], NRCS [South Africa]
Dimensions
- Width: 10.7 in. (27.2 cm)
- Height: 7.7 in. (19.5 cm)
- Depth: 4.4 in. (11.2 cm)
